Class 12 : Maths (English) – Chapter 11: Three Dimensional Geometry

Posted by

On June 25, 2025

EXPLANATION & SUMMARY

🔷 Explanation Section (~1700 Words)
🔹 Introduction
Three Dimensional Geometry (3D Geometry) deals with the study of points, lines, and planes in three-dimensional space. In two dimensions (2D), we use x and y axes; in 3D, we introduce a third axis — z-axis, perpendicular to both x and y.
A point in 3D space is represented as P(x, y, z).

🔹 1. Coordinate Axes and Coordinate Planes
There are three mutually perpendicular axes:
X-axis
Y-axis
Z-axis
They intersect at the origin (O).
The planes formed:
XY-plane: z = 0
YZ-plane: x = 0
ZX-plane: y = 0
💡 Concept: The 3D coordinate system divides space into 8 octants.

🔹 2. Distance Formula
For two points P(x₁, y₁, z₁) and Q(x₂, y₂, z₂),
➡️ Distance (PQ) = √[(x₂ − x₁)² + (y₂ − y₁)² + (z₂ − z₁)²]
✏️ Note: It generalizes the 2D distance formula by adding the z-component.

🔹 3. Section Formula
If point P(x, y, z) divides the line joining A(x₁, y₁, z₁) and B(x₂, y₂, z₂) in ratio m : n, then:
➡️ x = (m·x₂ + n·x₁) / (m + n)
➡️ y = (m·y₂ + n·y₁) / (m + n)
➡️ z = (m·z₂ + n·z₁) / (m + n)
✔️ If m = n, it’s the midpoint.

🔹 4. Direction Cosines (l, m, n)
The direction cosines of a line are the cosines of the angles (α, β, γ) that the line makes with the x, y, and z axes respectively.
➡️ l = cos α, m = cos β, n = cos γ
✔️ Relation: l² + m² + n² = 1
✏️ Note: Direction cosines help represent a line’s orientation.

🔹 5. Direction Ratios (DRs)
If a, b, c are proportional to direction cosines, they are called direction ratios.
They satisfy: l / a = m / b = n / c
💡 Concept: Any set of numbers proportional to direction cosines can be used as DRs.

🔹 6. Equation of a Line
(i) Vector Form
If a line passes through point A(a₁, a₂, a₃) and is parallel to vector b̅ = b₁î + b₂ĵ + b₃k̂,
➡️ Equation: r̅ = a̅ + λ b̅, where λ ∈ ℝ
(ii) Cartesian Form
From vector form,
➡️ (x − a₁)/b₁ = (y − a₂)/b₂ = (z − a₃)/b₃
✏️ Note: Each ratio equals parameter λ.

🔹 7. Condition for Parallel and Perpendicular Lines
Let DRs of lines L₁ and L₂ be (a₁, b₁, c₁) and (a₂, b₂, c₂):
✔️ Parallel: a₁/a₂ = b₁/b₂ = c₁/c₂
✔️ Perpendicular: a₁a₂ + b₁b₂ + c₁c₂ = 0

🔹 8. Shortest Distance Between Two Lines
If two lines are skew, the shortest distance (d) is given by:
➡️ d = |(a₂ − a₁) ⋅ (b₁ × b₂)| / |b₁ × b₂|
💡 Concept: Skew lines are non-intersecting and non-parallel.

🔹 9. Equation of a Plane
(i) Vector Form
If a plane passes through point A(a₁, a₂, a₃) with normal vector n̅ = n₁î + n₂ĵ + n₃k̂,
➡️ Equation: (r̅ − a̅) ⋅ n̅ = 0
(ii) Cartesian Form
➡️ n₁(x − a₁) + n₂(y − a₂) + n₃(z − a₃) = 0
Or
➡️ n₁x + n₂y + n₃z + D = 0

🔹 10. Normal Form
If the plane is at distance p from origin and normal makes direction cosines (l, m, n),
➡️ lx + my + nz = p

🔹 11. Intercept Form
➡️ x/a + y/b + z/c = 1
where a, b, c are intercepts on the axes.

🔹 12. Angle Between Two Planes
If planes are:
P₁: A₁x + B₁y + C₁z + D₁ = 0
P₂: A₂x + B₂y + C₂z + D₂ = 0
➡️ cos θ = (A₁A₂ + B₁B₂ + C₁C₂) / [√(A₁²+B₁²+C₁²) · √(A₂²+B₂²+C₂²)]

🔹 13. Angle Between a Line and a Plane
If line has DRs (a, b, c) and plane has normal (A, B, C):
➡️ sin θ = (A·a + B·b + C·c) / [√(A²+B²+C²) · √(a²+b²+c²)]

🔹 14. Condition for Line Parallel/Perpendicular to Plane
✔️ Parallel: A·a + B·b + C·c = 0
✔️ Perpendicular: a/A = b/B = c/C

🔹 15. Distance of a Point from a Plane
For point P(x₁, y₁, z₁) and plane Ax + By + Cz + D = 0:
➡️ Distance (d) = |A·x₁ + B·y₁ + C·z₁ + D| / √(A² + B² + C²)

🔹 16. Equation of Plane Passing Through Three Points
Given A(x₁, y₁, z₁), B(x₂, y₂, z₂), C(x₃, y₃, z₃):
Form vectors AB̅ and AC̅,
Normal n̅ = AB̅ × AC̅,
Then plane equation: (r̅ − a̅) ⋅ n̅ = 0

🔹 17. Coplanarity Condition for Lines
Two lines with DRs (a₁, b₁, c₁), (a₂, b₂, c₂) and position vectors a̅₁, a̅₂ are coplanar if:
➡️ (a₂ − a₁) ⋅ (b₁ × b₂) = 0

🔹 18. Distance Between Two Parallel Planes
For Ax + By + Cz + D₁ = 0 and Ax + By + Cz + D₂ = 0:
➡️ Distance = |D₁ − D₂| / √(A² + B² + C²)

🔹 19. Angle Between Line and Line
If direction ratios of two lines are (a₁, b₁, c₁) and (a₂, b₂, c₂):
➡️ cos θ = (a₁a₂ + b₁b₂ + c₁c₂) / [√(a₁² + b₁² + c₁²) · √(a₂² + b₂² + c₂²)]

🔹 20. Miscellaneous Results
If a line lies in a plane, its DRs satisfy plane equation.
Skew lines never intersect and are not parallel.
Intersection line of two planes can be found by cross product of normals.

🔷 Summary (~300 Words)
🔹 Key Formulas:
Distance: √[(x₂−x₁)² + (y₂−y₁)² + (z₂−z₁)²]
Section Formula: ((mx₂ + nx₁)/(m+n), …)
Line (Vector): r̅ = a̅ + λb̅
Line (Cartesian): (x−x₁)/a = (y−y₁)/b = (z−z₁)/c
Plane (Vector): (r̅ − a̅) ⋅ n̅ = 0
Plane (Cartesian): Ax + By + Cz + D = 0
Angle (line-line): cos θ = (a₁a₂ + b₁b₂ + c₁c₂)/(…)
Angle (plane-plane): cos θ = (A₁A₂ + B₁B₂ + C₁C₂)/(…)
Point-plane distance: |Ax₁ + By₁ + Cz₁ + D| / √(A² + B² + C²)
Parallel plane distance: |D₁ − D₂| / √(A² + B² + C²)
Shortest distance (skew lines): |(a₂−a₁) ⋅ (b₁×b₂)| / |b₁×b₂|

🔹 Important Concepts:
Direction cosines (l, m, n) satisfy l² + m² + n² = 1
Direction ratios proportional to cosines
Line: single parameter λ; Plane: normal vector defines orientation
Relations between line & plane help analyze geometry in 3D

🔹 Applications:
Used in physics (motion, forces)
Engineering design, computer graphics, navigation, robotics, architecture

📝 Quick Recap:
✔️ 3D point: P(x, y, z)
✔️ Line: r̅ = a̅ + λb̅
✔️ Plane: (r̅ − a̅) ⋅ n̅ = 0
✔️ Distance & angles from formulas
✔️ Direction cosines: l² + m² + n² = 1
✔️ Point-plane distance formula essential
✔️ Skew line shortest distance via vector triple product

————————————————————————————————————————————————————————————————————————————

QUESTIONS FROM TEXTBOOK

Exercise 11.1

🔵 Question 1:
If a line makes angles 90°, 135°, 45° with the x, y and z-axes respectively, find its direction cosines.
🟢 Answer:
➡️ Let direction cosines be l = cos α, m = cos β, n = cos γ.
➡️ Given: α = 90°, β = 135°, γ = 45°.
✳️ Step 1:
l = cos 90° = 0
✳️ Step 2:
m = cos 135° = −1 / √2
✳️ Step 3:
n = cos 45° = 1 / √2
✏️ Check:
l² + m² + n² = 0² + (−1/√2)² + (1/√2)² = 0 + 1/2 + 1/2 = 1 ✔️
✔️ Final Direction Cosines: (0, −1 / √2, 1 / √2)
🔵 Question 2:
Find the direction cosines of a line which makes equal angles with the coordinate axes.
🟢 Answer:
➡️ Let the line make equal angles ⇒ α = β = γ.
➡️ Therefore, l = m = n.
✳️ Step 1:
Use identity l² + m² + n² = 1.
✳️ Step 2:
3 l² = 1 ⇒ l² = 1 / 3 ⇒ l = 1 / √3.
✏️ Hence, l = m = n = 1 / √3.
✔️ Final Direction Cosines: (1 / √3, 1 / √3, 1 / √3)
💡 Note: Opposite direction is (−1 / √3, −1 / √3, −1 / √3).
🔵 Question 3:
If a line has the direction ratios −18, 12, −4, then what are its direction cosines?
🟢 Answer:
➡️ Given direction ratios: a = −18, b = 12, c = −4.
✳️ Step 1:
Find magnitude k = √(a² + b² + c²)
= √( (−18)² + 12² + (−4)² )
= √(324 + 144 + 16) = √484 = 22.
✳️ Step 2:
Compute direction cosines:
l = a / k = −18 / 22 = −9 / 11
m = b / k = 12 / 22 = 6 / 11
n = c / k = −4 / 22 = −2 / 11
✏️ Check:
(−9/11)² + (6/11)² + (−2/11)² = 81/121 + 36/121 + 4/121 = 121/121 = 1 ✔️
✔️ Final Direction Cosines: (−9 / 11, 6 / 11, −2 / 11)
🔵 Question 4:
Show that the points (2, 3, 4), (−1, −2, 1), (5, 8, 7) are collinear.
🟢 Answer:
➡️ Let A(2, 3, 4), B(−1, −2, 1), C(5, 8, 7).
✳️ Step 1:
Find AB = B − A = (−1−2, −2−3, 1−4) = (−3, −5, −3).
✳️ Step 2:
Find AC = C − A = (5−2, 8−3, 7−4) = (3, 5, 3).
✳️ Step 3:
Observe that AB = −1 × AC.
➡️ Therefore, AB and AC are parallel and pass through point A.
✔️ Conclusion: Points A, B, C are collinear.
🔵 Question 5:
Find the direction cosines of the sides of the triangle whose vertices are (3, 5, −4), (−1, 1, 2) and (−5, −5, −2).
🟢 Answer:
➡️ Let A(3, 5, −4), B(−1, 1, 2), C(−5, −5, −2).

✳️ Side AB:
AB = B − A = (−1−3, 1−5, 2−(−4)) = (−4, −4, 6).
|AB| = √( (−4)² + (−4)² + 6² ) = √(16 + 16 + 36) = √68 = 2√17.
➡️ Direction cosines of AB:
l₁ = −4 / 2√17 = −2 / √17
m₁ = −4 / 2√17 = −2 / √17
n₁ = 6 / 2√17 = 3 / √17
✔️ AB → (−2 / √17, −2 / √17, 3 / √17)

✳️ Side BC:
BC = C − B = (−5−(−1), −5−1, −2−2) = (−4, −6, −4).
|BC| = √( (−4)² + (−6)² + (−4)² ) = √(16 + 36 + 16) = √68 = 2√17.
➡️ Direction cosines of BC:
l₂ = −4 / 2√17 = −2 / √17
m₂ = −6 / 2√17 = −3 / √17
n₂ = −4 / 2√17 = −2 / √17
✔️ BC → (−2 / √17, −3 / √17, −2 / √17)

✳️ Side CA:
CA = A − C = (3−(−5), 5−(−5), −4−(−2)) = (8, 10, −2).
|CA| = √(8² + 10² + (−2)²) = √(64 + 100 + 4) = √168 = 2√42.
➡️ Direction cosines of CA:
l₃ = 8 / 2√42 = 4 / √42
m₃ = 10 / 2√42 = 5 / √42
n₃ = −2 / 2√42 = −1 / √42
✔️ CA → (4 / √42, 5 / √42, −1 / √42)

✔️ Final Answers:
🔹 AB → (−2 / √17, −2 / √17, 3 / √17)
🔹 BC → (−2 / √17, −3 / √17, −2 / √17)
🔹 CA → (4 / √42, 5 / √42, −1 / √42)

Exercise 11.2

🔵 Question 1:
Show that the three lines with direction cosines 12/13, −3/13, −4/13; 4/13, 12/13, 3/13; 3/13, −4/13, 12/13 are mutually perpendicular.

🟢 Answer:
➡️ Let the three direction-cosine triplets be
L₁ = (12/13, −3/13, −4/13), L₂ = (4/13, 12/13, 3/13), L₃ = (3/13, −4/13, 12/13).
➡️ Two lines are perpendicular ⇔ dot product of their direction cosines is 0.

✳️ Step 1 (L₁ ⋅ L₂):
(12/13)(4/13) + (−3/13)(12/13) + (−4/13)(3/13)
= 48/169 − 36/169 − 12/169 = 0. ✔️

✳️ Step 2 (L₁ ⋅ L₃):
(12/13)(3/13) + (−3/13)(−4/13) + (−4/13)(12/13)
= 36/169 + 12/169 − 48/169 = 0. ✔️

✳️ Step 3 (L₂ ⋅ L₃):
(4/13)(3/13) + (12/13)(−4/13) + (3/13)(12/13)
= 12/169 − 48/169 + 36/169 = 0. ✔️

✔️ Final: All pairwise dot products are 0 ⇒ the three lines are mutually perpendicular.

🔵 Question 2:
Show that the line through the points (1, −1, 2), (3, 4, −2) is perpendicular to the line through the points (0, 3, 2) and (3, 5, 6).

🟢 Answer:
➡️ Direction ratios of line ℓ₁ through P₁(1, −1, 2), P₂(3, 4, −2):
✳️ Step 1: P₁P₂ = (3−1, 4−(−1), −2−2) = (2, 5, −4).

➡️ Direction ratios of line ℓ₂ through Q₁(0, 3, 2), Q₂(3, 5, 6):
✳️ Step 2: Q₁Q₂ = (3−0, 5−3, 6−2) = (3, 2, 4).

✳️ Step 3 (Dot product test):
(2, 5, −4) ⋅ (3, 2, 4) = 2×3 + 5×2 + (−4)×4 = 6 + 10 − 16 = 0.

✔️ Final: Dot product = 0 ⇒ the two lines are perpendicular.

🔵 Question 3:
Show that the line through the points (4, 7, 8), (2, 3, 4) is parallel to the line through the points (−1, −2, 1), (1, 2, 5).

🟢 Answer:
➡️ Direction ratios of line ℓ₁ through A(4, 7, 8), B(2, 3, 4):
✳️ Step 1: AB = (2−4, 3−7, 4−8) = (−2, −4, −4).

➡️ Direction ratios of line ℓ₂ through C(−1, −2, 1), D(1, 2, 5):
✳️ Step 2: CD = (1−(−1), 2−(−2), 5−1) = (2, 4, 4).

✳️ Step 3 (Scalar multiple test):
(−2, −4, −4) = −1 × (2, 4, 4).

✔️ Final: Direction ratios are proportional ⇒ the two lines are parallel.

🔵 Question 4:
Find the equation of the line which passes through the point (1, 2, 3) and is parallel to the vector 3i + 2j − 2k.

🟢 Answer:
➡️ Point vector: r₀ = 1i + 2j + 3k.
➡️ Direction vector: a = 3i + 2j − 2k.

✳️ Step 1 (Vector form):
r⃗ = r₀ + λ a = (i + 2j + 3k) + λ(3i + 2j − 2k), λ ∈ ℝ.

✳️ Step 2 (Cartesian form):
(x − 1)/3 = (y − 2)/2 = (z − 3)/(−2).

✔️ Final: Required line is r⃗ = (i + 2j + 3k) + λ(3i + 2j − 2k) and (x − 1)/3 = (y − 2)/2 = (z − 3)/(−2).

🔵 Question 5:
Find the equation of the line in vector and in cartesian form that passes through the point with position vector 2i − j + 4k and is in the direction i + 2j − k.

🟢 Answer:
➡️ Given point vector r₀ = 2i − j + 4k.
➡️ Given direction vector a = i + 2j − k.

✳️ Step 1 (Vector form):
r⃗ = r₀ + λ a = (2i − j + 4k) + λ(i + 2j − k), λ ∈ ℝ.

✳️ Step 2 (Cartesian form using direction ratios 1, 2, −1):
(x − 2)/1 = (y + 1)/2 = (z − 4)/(−1).

✔️ Final: r⃗ = (2i − j + 4k) + λ(i + 2j − k); (x − 2)/1 = (y + 1)/2 = (z − 4)/(−1).

🔵 Question 6:
Find the cartesian equation of the line which passes through the point (−2, 4, −5) and parallel to the line given by (x + 3)/3 = (y − 4)/5 = (z + 8)/6.

🟢 Answer:
➡️ A line parallel to (x + 3)/3 = (y − 4)/5 = (z + 8)/6 has direction ratios 3, 5, 6.
➡️ Required line must pass through (−2, 4, −5) with same direction ratios.

✳️ Step 1 (Cartesian form):
(x − (−2))/3 = (y − 4)/5 = (z − (−5))/6.

✳️ Step 2 (Simplify brackets):
(x + 2)/3 = (y − 4)/5 = (z + 5)/6.

✔️ Final: (x + 2)/3 = (y − 4)/5 = (z + 5)/6.

🔵 Question 7:
The cartesian equation of a line is (x − 5)/3 = (y + 4)/7 = (z − 6)/2. Write its vector form.

🟢 Answer:
➡️ From the given form, a point on the line is (5, −4, 6).
➡️ Direction ratios are 3, 7, 2 ⇒ direction vector a = 3i + 7j + 2k.

✳️ Step 1 (Vector form using r₀ = 5i − 4j + 6k):
r⃗ = r₀ + λ a = (5i − 4j + 6k) + λ(3i + 7j + 2k), λ ∈ ℝ.

✔️ Final: r⃗ = (5i − 4j + 6k) + λ(3i + 7j + 2k).

🔵 Question 8:
Find the angle between the following pairs of lines:

(i) r⃗ = 2i − 5j + k + λ(3i + 2j + 6k) and r⃗ = 7i − 6k + μ(i + 2j + 2k)

(ii) r⃗ = 3i + j − 2k + λ(i − j − 2k) and r⃗ = 2i − j − 56k + μ(3i − 5j − 4k)

🟢 Answer (common idea):
➡️ If a₁ and a₂ are direction vectors, then cos θ = (a₁ ⋅ a₂) / (|a₁| |a₂|), with 0° ≤ θ ≤ 180°.

✳️ Part (i):
➡️ a₁ = 3i + 2j + 6k ⇒ components (3, 2, 6).
➡️ a₂ = i + 2j + 2k ⇒ components (1, 2, 2).
➡️ a₁ ⋅ a₂ = 3×1 + 2×2 + 6×2 = 3 + 4 + 12 = 19.
➡️ |a₁| = √(3² + 2² + 6²) = √(9 + 4 + 36) = √49 = 7.
➡️ |a₂| = √(1² + 2² + 2²) = √(1 + 4 + 4) = √9 = 3.
➡️ cos θ = 19 / (7 × 3) = 19/21.
✔️ Angle: θ = cos⁻¹(19/21).

✳️ Part (ii):
➡️ a₁ = i − j − 2k ⇒ components (1, −1, −2).
➡️ a₂ = 3i − 5j − 4k ⇒ components (3, −5, −4).
➡️ a₁ ⋅ a₂ = 1×3 + (−1)×(−5) + (−2)×(−4) = 3 + 5 + 8 = 16.
➡️ |a₁| = √(1² + (−1)² + (−2)²) = √(1 + 1 + 4) = √6.
➡️ |a₂| = √(3² + (−5)² + (−4)²) = √(9 + 25 + 16) = √50 = 5√2.
➡️ cos θ = 16 / (√6 × 5√2) = 16 / (5 √12) = 16 / (10 √3) = 8 / (5 √3).
✔️ Angle: θ = cos⁻¹(8 / (5 √3)).

✔️ Final Answers:
(i) θ = cos⁻¹(19/21)
(ii) θ = cos⁻¹(8 / (5 √3))

🔵 Question 9:
Find the angle between the following pair of lines:

(i) (x − 2)/2 = (y − 1)/5 = (z + 3)/−3 and (x + 2)/−1 = (y − 4)/8 = (z − 5)/4

(ii) x/2 = y/2 = z/1 and (x − 5)/4 = (y − 2)/1 = (z − 3)/8

🟢 Answer:
➡️ Idea: If direction vectors are a and b, then cos θ = (a · b) / (|a| |b|).

✳️ Part (i):
➡️ Direction ratios a₁ = (2, 5, −3), a₂ = (−1, 8, 4).
➡️ a₁ · a₂ = 2(−1) + 5×8 + (−3)×4 = −2 + 40 − 12 = 26.
➡️ |a₁| = √(2² + 5² + (−3)²) = √(4 + 25 + 9) = √38.
➡️ |a₂| = √((−1)² + 8² + 4²) = √(1 + 64 + 16) = √81 = 9.
➡️ cos θ = 26 / (9 √38).
✔️ Angle: θ = cos⁻¹( 26 / (9 √38) ).

✳️ Part (ii):
➡️ Direction ratios a₁ = (2, 2, 1), a₂ = (4, 1, 8).
➡️ a₁ · a₂ = 2×4 + 2×1 + 1×8 = 8 + 2 + 8 = 18.
➡️ |a₁| = √(2² + 2² + 1²) = √9 = 3.
➡️ |a₂| = √(4² + 1² + 8²) = √81 = 9.
➡️ cos θ = 18 / (3 × 9) = 2/3.
✔️ Angle: θ = cos⁻¹(2/3).

🔵 Question 10:
Find the values of p so that the lines (1 − x)/3 = (7y − 14)/(2p) = (z − 3)/2 and (7 − 7x)/(3p) = y/5 = (6 − z)/5 are at right angles.

🟢 Answer:
➡️ Line 1: take parameter t.
➡️ x = 1 − 3t ⇒ dx/dt = −3, 7y − 14 = 2pt ⇒ dy/dt = 2p/7, z = 3 + 2t ⇒ dz/dt = 2.
➡️ Direction ratios of Line 1 ∝ (−3, 2p/7, 2) ⇒ choose (−21, 2p, 14).

➡️ Line 2: take parameter s.
➡️ 7 − 7x = 3ps ⇒ x = 1 − (3p/7)s ⇒ dx/ds = −3p/7, y = 5s ⇒ dy/ds = 5, 6 − z = 5s ⇒ dz/ds = −5.
➡️ Direction ratios of Line 2 ∝ (−3p/7, 5, −5) ⇒ choose (−3p, 35, −35).

➡️ Perpendicular condition: (−21, 2p, 14) · (−3p, 35, −35) = 0.
➡️ 63p + 70p − 490 = 0 ⇒ 133p = 490 ⇒ p = 490/133 = 70/19.
✔️ Final: p = 70/19.

🔵 Question 11:
Show that the lines (x − 5)/7 = (y + 2)/−5 = z/1 and x/1 = y/2 = z/3 are perpendicular to each other.

🟢 Answer:
➡️ Direction ratios: Line 1 → (7, −5, 1); Line 2 → (1, 2, 3).
➡️ Dot product = 7×1 + (−5)×2 + 1×3 = 7 − 10 + 3 = 0.
✔️ Conclusion: Dot product 0 ⇒ lines are perpendicular.

🔵 Question 12:
Find the shortest distance between the lines
r̅ = (i + 2 j + k) + λ (i − j + k) and r̅ = 2 i − j − k + μ (2 i + j + 2 k).

🟢 Answer:
➡️ Point on Line 1: A(1, 2, 1); direction b = (1, −1, 1).
➡️ Point on Line 2: C(2, −1, −1); direction d = (2, 1, 2).
➡️ Formula (skew lines): Shortest distance D = | ( (C − A) · (b × d) ) | / | b × d |.

✳️ Step 1: b × d = | i j k ; 1 −1 1 ; 2 1 2 | = (−3, 0, 3).
✳️ Step 2: C − A = (2 − 1, −1 − 2, −1 − 1) = (1, −3, −2).
✳️ Step 3: (C − A) · (b × d) = 1×(−3) + (−3)×0 + (−2)×3 = −3 + 0 − 6 = −9.
✳️ Step 4: |b × d| = √((−3)² + 0² + 3²) = √18 = 3√2.
✳️ Step 5: D = |−9| / (3√2) = 9 / (3√2) = 3 / √2 = (3√2)/2.

✔️ Shortest distance: D = 3/√2 = (3√2)/2.

🔵 Question 13:
Find the shortest distance between the lines
(x + 1)/7 = (y + 1)/(−6) = (z + 1)/1
and
(x − 3)/(−2) = (y − 5)/(−2) = (z − 7)/1.

🟢 Answer:

➡️ Step 1: Identify points and direction ratios
Line 1 passes through A(−1, −1, −1) and has direction ratios b = (7, −6, 1).
Line 2 passes through C(3, 5, 7) and has direction ratios d = (−2, −2, 1).

➡️ Step 2: Formula
Shortest distance between two skew lines:
D = | ( (C − A) ⋅ (b × d) ) | ÷ | b × d |

➡️ Step 3: Find cross product (b × d)
b = (7, −6, 1), d = (−2, −2, 1)
b × d =
| i j k |
| 7 −6 1 |
| −2 −2 1 |

= i( (−6)(1) − (1)(−2) ) − j( (7)(1) − (1)(−2) ) + k( (7)(−2) − (−6)(−2) )
= i( −6 + 2 ) − j( 7 + 2 ) + k( −14 − 12 )
= ( −4, −9, −26 )

➡️ Step 4: Find vector (C − A)
C − A = (3 − (−1), 5 − (−1), 7 − (−1))
C − A = (4, 6, 8)

➡️ Step 5: Dot product
(C − A) ⋅ (b × d) = 4(−4) + 6(−9) + 8(−26)
= (−16) + (−54) + (−208) = −278

➡️ Step 6: Magnitude of (b × d)
|b × d| = √( (−4)² + (−9)² + (−26)² )
= √(16 + 81 + 676) = √773

➡️ Step 7: Apply formula
D = | −278 | ÷ √773 = 278 ÷ √773

✔️ Final Answer:
Shortest distance D = 278 / √773

🔵 Question 14:
Find the shortest distance between the lines whose vector equations are
r̅ = (i + 2 j + 3 k) + λ (i − 3 j + 2 k) and r̅ = 4 i + 5 j + 6 k + μ (2 i + 3 j + k).

🟢 Answer:
➡️ Line 1 point A(1, 2, 3); direction b = (1, −3, 2).
➡️ Line 2 point C(4, 5, 6); direction d = (2, 3, 1).
➡️ Use D = | ( (C − A) ⋅ (b × d) ) | ÷ | b × d |.

✳️ Step 1: b × d = | i j k ; 1 −3 2 ; 2 3 1 | = (−9, 3, 9).
✳️ Step 2: C − A = (4 − 1, 5 − 2, 6 − 3) = (3, 3, 3).
✳️ Step 3: (C − A) ⋅ (b × d) = 3(−9) + 3×3 + 3×9 = −27 + 9 + 27 = 9.
✳️ Step 4: | b × d | = √( (−9)² + 3² + 9² ) = √171 = 3√19.
✳️ Step 5: D = |9| ÷ (3√19) = 3 ÷ √19.

✔️ Final Shortest Distance: D = 3/√19.

🔵 Question 15:
Find the shortest distance between the lines whose vector equations are
r̅ = (1 − t) i + (t − 2) j + (3 − 2 t) k and r̅ = (s + 1) i + (2 s − 1) j − (2 s + 1) k.

🟢 Answer:
➡️ Line 1 at t = 0 gives point A(1, −2, 3); direction b = d/dt = (−1, 1, −2).
➡️ Line 2 at s = 0 gives point C(1, −1, −1); direction d = d/ds = (1, 2, −2).
➡️ Use D = | ( (C − A) ⋅ (b × d) ) | ÷ | b × d |.

✳️ Step 1: b × d = | i j k ; −1 1 −2 ; 1 2 −2 | = (2, −4, −3).
✳️ Step 2: C − A = (1 − 1, −1 − (−2), −1 − 3) = (0, 1, −4).
✳️ Step 3: (C − A) ⋅ (b × d) = 0×2 + 1×(−4) + (−4)×(−3) = −4 + 12 = 8.
✳️ Step 4: | b × d | = √(2² + (−4)² + (−3)²) = √29.
✳️ Step 5: D = |8| ÷ √29 = 8 ÷ √29.

✔️ Final Shortest Distance: D = 8/√29.

JEE MAINS QUESTIONS FROM THIS LESSON

🔵 Question 1:
The direction cosines of a line equally inclined to the coordinate axes are
🟥 1️⃣ (1/√3, 1/√3, 1/√3)
🟩 2️⃣ (1/2, 1/2, 1/2)
🟨 3️⃣ (√3/2, √3/2, √3/2)
🟦 4️⃣ (0, 1, 1)
Answer: 1️⃣ (1/√3, 1/√3, 1/√3)
💡 Hint: For equal inclination, l = m = n, and l² + m² + n² = 1
📘 (JEE Main 2024 | Shift 1)

🔵 Question 2:
The cosine of the angle between the vectors a = 2i + j + 2k and b = i + 2j + 2k is
🟥 1️⃣ 1/2
🟩 2️⃣ 2/3
🟨 3️⃣ 3/4
🟦 4️⃣ 1
Answer: 1️⃣ 1/2
💡 Hint: cosθ = (a·b)/(|a||b|)
📘 (JEE Main 2024 | Shift 2)

🔵 Question 3:
The projection of the vector a = 3i + 4j + 12k on b = 6i – 8j + 0k is
🟥 1️⃣ 0
🟩 2️⃣ 3
🟨 3️⃣ 9
🟦 4️⃣ 12
Answer: 1️⃣ 0
📘 (JEE Main 2023 | Shift 1)

🔵 Question 4:
The acute angle between the lines r = (i + j) + λ(i + j + k) and r = (2i + 3j) + μ(2i – j + 2k) is
🟥 1️⃣ 60°
🟩 2️⃣ 45°
🟨 3️⃣ 90°
🟦 4️⃣ 30°
Answer: 1️⃣ 60°
📘 (JEE Main 2023 | Shift 2)

🔵 Question 5:
The equation of plane passing through (1, 2, 3) and perpendicular to vector 2i – j + 2k is
🟥 1️⃣ 2x – y + 2z – 8 = 0
🟩 2️⃣ 2x – y + 2z + 8 = 0
🟨 3️⃣ x – 2y + z = 0
🟦 4️⃣ 2x + y – 2z = 0
Answer: 1️⃣ 2x – y + 2z – 8 = 0
📘 (JEE Main 2022 | June)

🔵 Question 6:
The vector equation of line passing through (2, -1, 3) and parallel to vector i + 2j – k is
🟥 1️⃣ r = (2i – j + 3k) + t(i + 2j – k)
🟩 2️⃣ r = (2i + j – 3k) + t(i + 2j – k)
🟨 3️⃣ r = (2i – j + 3k) – t(i + 2j – k)
🟦 4️⃣ r = (2i – j + 3k) + t(-i – 2j + k)
Answer: 1️⃣ r = (2i – j + 3k) + t(i + 2j – k)
📘 (JEE Main 2022 | July)

🔵 Question 7:
The foot of perpendicular from the origin to the plane 2x – 3y + 6z = 7 is
🟥 1️⃣ (1, -1, 1)
🟩 2️⃣ (2/7, -3/7, 6/7)
🟨 3️⃣ (2, 3, 6)
🟦 4️⃣ (7, -7, 7)
Answer: 2️⃣ (2/7, -3/7, 6/7)
📘 (JEE Main 2021)

🔵 Question 8:
The equation of plane passing through (1, -1, 2) and perpendicular to both i + j + k and 2i – j + 3k is
🟥 1️⃣ x – 5y + 3z – 10 = 0
🟩 2️⃣ x + y – z + 2 = 0
🟨 3️⃣ x – y + z = 0
🟦 4️⃣ x + 2y + 3z = 0
Answer: 1️⃣ x – 5y + 3z – 10 = 0
📘 (JEE Main 2021)

🔵 Question 9:
Equation of line passing through intersection of planes x + y + z = 3 and 2x – y + 3z = 7 and parallel to y-axis is
🟥 1️⃣ (x, y, z) = (1, 0, 2) + t(0, 1, 0)
🟩 2️⃣ (x, y, z) = (0, 1, 2) + t(0, 1, 0)
🟨 3️⃣ (x, y, z) = (2, 0, 1) + t(0, 1, 0)
🟦 4️⃣ (x, y, z) = (3, 1, 0) + t(0, 1, 0)
Answer: 1️⃣ (x, y, z) = (1, 0, 2) + t(0, 1, 0)
📘 (JEE Main 2020)

🔵 Question 10:
If line L₁: (x – 1)/2 = (y + 1)/(-1) = (z – 2)/3 and L₂: x/3 = (y – 2)/2 = (z – 3)/(-2) intersect, their point of intersection is
🟥 1️⃣ (3, 1, 4)
🟩 2️⃣ (2, 0, 3)
🟨 3️⃣ (1, 2, 3)
🟦 4️⃣ (0, 1, 2)
Answer: 2️⃣ (2, 0, 3)
📘 (JEE Main 2020)

🔵 Question 11:
The distance of point (1, 2, 3) from plane 2x + 3y + 6z – 12 = 0 is
🟥 1️⃣ 1
🟩 2️⃣ 2
🟨 3️⃣ 3
🟦 4️⃣ 4
Answer: 2️⃣ 2
📘 (JEE Main 2019)

🔵 Question 12:
The angle between the line and plane is 30°, if direction ratios of line are (2, 3, 6), then direction cosines of normal to plane are
🟥 1️⃣ (1/7, 3/7, 6/7)
🟩 2️⃣ (1/√7, 3/√7, 6/√7)
🟨 3️⃣ (2/7, 3/7, 6/7)
🟦 4️⃣ (2/√7, 3/√7, 6/√7)
Answer: 2️⃣ (1/√7, 3/√7, 6/√7)
📘 (JEE Main 2018)

🔵 Question 13:
If a line makes angles 90°, 45°, 45° with x-, y-, z-axes respectively, its direction cosines are
🟥 1️⃣ (0, 1/√2, 1/√2)
🟩 2️⃣ (1/√2, 1/√2, 0)
🟨 3️⃣ (1/√3, 1/√3, 1/√3)
🟦 4️⃣ (1, 0, 0)
Answer: 1️⃣ (0, 1/√2, 1/√2)
📘 (JEE Main 2017)

🔵 Question 14:
Equation of line through (1, 2, 3) parallel to both lines x = y = z and x – 1 = (y – 2)/2 = (z – 3)/3 is
🟥 1️⃣ x – 1 = (y – 2)/2 = (z – 3)/3
🟩 2️⃣ (x – 1)/1 = (y – 2)/2 = (z – 3)/3
🟨 3️⃣ (x – 1)/2 = (y – 2)/1 = (z – 3)/1
🟦 4️⃣ (x – 1)/1 = (y – 2)/1 = (z – 3)/1
Answer: 2️⃣ (x – 1)/1 = (y – 2)/2 = (z – 3)/3
📘 (JEE Main 2016)

🔵 Question 15:
Equation of plane passing through (1, -2, 3) and parallel to plane 2x – 3y + 4z + 5 = 0 is
🟥 1️⃣ 2x – 3y + 4z – 20 = 0
🟩 2️⃣ 2x – 3y + 4z + 20 = 0
🟨 3️⃣ 2x – 3y + 4z – 5 = 0
🟦 4️⃣ 2x – 3y + 4z = 0
Answer: 1️⃣ 2x – 3y + 4z – 20 = 0
📘 (JEE Main 2015)

🔵 Question 16:
If a line has direction cosines l, m, n then l² + m² + n² equals
🟥 1️⃣ 0
🟩 2️⃣ 1
🟨 3️⃣ 2
🟦 4️⃣ 3
Answer: 2️⃣ 1
📘 (JEE Main 2015)

🔵 Question 17:
If line passes through points (2, 3, 4) and (4, 7, 6), its symmetric form is
🟥 1️⃣ (x – 2)/2 = (y – 3)/4 = (z – 4)/2
🟩 2️⃣ (x + 2)/2 = (y + 3)/4 = (z + 4)/2
🟨 3️⃣ (x – 2)/1 = (y – 3)/2 = (z – 4)/1
🟦 4️⃣ (x – 2)/3 = (y – 3)/2 = (z – 4)/3
Answer: 1️⃣ (x – 2)/2 = (y – 3)/4 = (z – 4)/2
📘 (JEE Main 2014)

🔵 Question 21:
The distance between the planes 2x + 3y + 6z = 7 and 2x + 3y + 6z = -5 is
🟥 1️⃣ 2
🟩 2️⃣ 3/√7
🟨 3️⃣ 12/7
🟦 4️⃣ 12/√49
Answer: 3️⃣ 12/7
📘 (JEE Main 2014)

🔵 Question 22:
The equation of plane passing through point (1, 2, 3) and perpendicular to vector (2, -3, 4) is
🟥 1️⃣ 2x – 3y + 4z – 20 = 0
🟩 2️⃣ 2x – 3y + 4z – 16 = 0
🟨 3️⃣ 2x + 3y – 4z = 0
🟦 4️⃣ 2x – 3y + 4z + 16 = 0
Answer: 2️⃣ 2x – 3y + 4z – 16 = 0
📘 (JEE Main 2014)

🔵 Question 23:
The direction cosines of a line equally inclined to coordinate axes are
🟥 1️⃣ (1/√3, 1/√3, 1/√3)
🟩 2️⃣ (1/2, 1/2, 1/2)
🟨 3️⃣ (√3/2, √3/2, √3/2)
🟦 4️⃣ (0, 1, 1)
Answer: 1️⃣ (1/√3, 1/√3, 1/√3)
📘 (JEE Main 2013)

🔵 Question 24:
The equation of plane passing through point (2, 3, 4) and parallel to plane x + 2y + 2z = 5 is
🟥 1️⃣ x + 2y + 2z – 16 = 0
🟩 2️⃣ x + 2y + 2z + 16 = 0
🟨 3️⃣ x + 2y + 2z = 0
🟦 4️⃣ x + 2y + 2z – 5 = 0
Answer: 1️⃣ x + 2y + 2z – 16 = 0
📘 (JEE Main 2013)

🔵 Question 25:
Equation of line passing through (1, 2, 3) and perpendicular to plane 2x – 3y + z + 7 = 0 is
🟥 1️⃣ (x – 1)/2 = (y – 2)/(-3) = (z – 3)/1
🟩 2️⃣ (x – 1)/(-2) = (y – 2)/3 = (z – 3)/(-1)
🟨 3️⃣ (x – 1)/1 = (y – 2)/2 = (z – 3)/3
🟦 4️⃣ (x – 1)/3 = (y – 2)/2 = (z – 3)/1
Answer: 1️⃣ (x – 1)/2 = (y – 2)/(-3) = (z – 3)/1
📘 (JEE Main 2012)

🔵 Question 26:
The foot of perpendicular from the point (3, 2, 1) to plane 2x + y – 2z + 3 = 0 is
🟥 1️⃣ (2, 1, 0)
🟩 2️⃣ (3, 1, -1)
🟨 3️⃣ (4, 2, 2)
🟦 4️⃣ (0, 0, 0)
Answer: 1️⃣ (2, 1, 0)
📘 (JEE Main 2012)

🔵 Question 27:
Equation of plane passing through point (1, -2, 3) and perpendicular to line (x – 1)/2 = (y + 2)/(-1) = (z – 3)/3 is
🟥 1️⃣ 2x – y + 3z – 15 = 0
🟩 2️⃣ 2x – y + 3z + 15 = 0
🟨 3️⃣ 2x + y – 3z = 0
🟦 4️⃣ x – y + z = 0
Answer: 1️⃣ 2x – y + 3z – 15 = 0
📘 (JEE Main 2011)

🔵 Question 28:
Equation of plane passing through origin and perpendicular to vector (3, -2, 6) is
🟥 1️⃣ 3x – 2y + 6z = 0
🟩 2️⃣ 3x + 2y – 6z = 0
🟨 3️⃣ x + y + z = 0
🟦 4️⃣ x – y + z = 0
Answer: 1️⃣ 3x – 2y + 6z = 0
📘 (AIEEE 2011)

🔵 Question 29:
Equation of plane passing through (1, 0, 0), (0, 1, 0), and (0, 0, 1) is
🟥 1️⃣ x + y + z = 1
🟩 2️⃣ x + y + z = 0
🟨 3️⃣ x + y + z = 2
🟦 4️⃣ x + y + z = 3
Answer: 1️⃣ x + y + z = 1
📘 (AIEEE 2010)

🔵 Question 30:
Direction ratios of a line perpendicular to plane 3x – 4y + 12z = 5 are
🟥 1️⃣ (3, -4, 12)
🟩 2️⃣ (1, 1, 1)
🟨 3️⃣ (12, 4, 3)
🟦 4️⃣ (2, 2, 2)
Answer: 1️⃣ (3, -4, 12)
📘 (AIEEE 2010)

🔵 Question 31:
Distance between parallel planes 4x – 3y + 12z + 5 = 0 and 4x – 3y + 12z – 9 = 0 is
🟥 1️⃣ 14/13
🟩 2️⃣ 7/13
🟨 3️⃣ 1
🟦 4️⃣ 2
Answer: 1️⃣ 14/13
📘 (AIEEE 2009)

🔵 Question 32:
Equation of line passing through point (2, 1, 1) and parallel to vector (1, 2, 2) is
🟥 1️⃣ (x – 2)/1 = (y – 1)/2 = (z – 1)/2
🟩 2️⃣ (x – 2)/2 = (y – 1)/1 = (z – 1)/2
🟨 3️⃣ (x – 2)/2 = (y – 1)/2 = (z – 1)/1
🟦 4️⃣ (x – 2)/1 = (y – 1)/1 = (z – 1)/1
Answer: 1️⃣ (x – 2)/1 = (y – 1)/2 = (z – 1)/2
📘 (AIEEE 2008)

🔵 Question 33:
Equation of plane equidistant from points (3, -1, 2) and (1, 3, 4) is
🟥 1️⃣ x – 2y + z = 0
🟩 2️⃣ x + 2y – z = 0
🟨 3️⃣ x – y + z = 0
🟦 4️⃣ x + y + z = 0
Answer: 1️⃣ x – 2y + z = 0
📘 (AIEEE 2008)

🔵 Question 34:
Equation of plane passing through (2, 1, 1) and perpendicular to vector (1, 2, 2) is
🟥 1️⃣ x + 2y + 2z – 6 = 0
🟩 2️⃣ x + 2y + 2z = 0
🟨 3️⃣ x + 2y + 2z + 6 = 0
🟦 4️⃣ 2x + y + z = 0
Answer: 1️⃣ x + 2y + 2z – 6 = 0
📘 (AIEEE 2007)

🔵 Question 35:
If a plane passes through origin and is perpendicular to line x = 1 + t, y = 2 – t, z = 3 + 2t, its equation is
🟥 1️⃣ x – y + 2z = 0
🟩 2️⃣ x + y + 2z = 0
🟨 3️⃣ x + y – 2z = 0
🟦 4️⃣ x – y – 2z = 0
Answer: 1️⃣ x – y + 2z = 0
📘 (AIEEE 2006)

🔵 Question 36:
Equation of line through (1, 2, 3) and parallel to vector (2, -1, 2) is
🟥 1️⃣ (x – 1)/2 = (y – 2)/(-1) = (z – 3)/2
🟩 2️⃣ (x – 1)/1 = (y – 2)/(-2) = (z – 3)/1
🟨 3️⃣ (x – 1)/2 = (y – 2)/1 = (z – 3)/2
🟦 4️⃣ (x – 1)/(-2) = (y – 2)/1 = (z – 3)/(-2)
Answer: 1️⃣ (x – 1)/2 = (y – 2)/(-1) = (z – 3)/2
📘 (AIEEE 2005)

🔵 Question 37:
Equation of plane passing through points (2, 3, 4), (1, -1, 2), (3, 2, 1) is
🟥 1️⃣ 3x – 4y + 2z – 10 = 0
🟩 2️⃣ 4x – 3y + 2z – 10 = 0
🟨 3️⃣ x – y + z – 10 = 0
🟦 4️⃣ x + y + z = 10
Answer: 1️⃣ 3x – 4y + 2z – 10 = 0
📘 (AIEEE 2004)

🔵 Question 38:
Equation of plane bisecting the angle between planes x + y + z = 4 and 2x + 2y + 2z = 8 is
🟥 1️⃣ x + y + z = 2
🟩 2️⃣ x + y + z = 3
🟨 3️⃣ x + y + z = 1
🟦 4️⃣ x + y + z = 0
Answer: 2️⃣ x + y + z = 3
📘 (AIEEE 2004)

🔵 Question 39:
Equation of line passing through (2, 3, 4) and parallel to x-axis is
🟥 1️⃣ x = 2 + t, y = 3, z = 4
🟩 2️⃣ x = 2, y = 3 + t, z = 4
🟨 3️⃣ x = 2, y = 3, z = 4 + t
🟦 4️⃣ x = 2 + t, y = 3 + t, z = 4 + t
Answer: 1️⃣ x = 2 + t, y = 3, z = 4
📘 (AIEEE 2003)

🔵 Question 40:
Cosine of angle between planes x + y + z = 0 and x – y + z = 0 is
🟥 1️⃣ 1/2
🟩 2️⃣ 2/3
🟨 3️⃣ 1/3
🟦 4️⃣ 0
Answer: 2️⃣ 2/3
📘 (AIEEE 2003)

🔵 Question 41:
Direction cosines of line perpendicular to both i + j + k and i – j + k are
🟥 1️⃣ (0, 1/√2, -1/√2)
🟩 2️⃣ (1/√2, 0, -1/√2)
🟨 3️⃣ (1/√2, 1/√2, 0)
🟦 4️⃣ (0, 1/√2, 1/√2)
Answer: 1️⃣ (0, 1/√2, -1/√2)
📘 (AIEEE 2002)

🔵 Question 42:
Equation of plane passing through (2, 1, 1) and perpendicular to vector (1, 2, 2) is
🟥 1️⃣ x + 2y + 2z – 6 = 0
🟩 2️⃣ x + 2y + 2z = 0
🟨 3️⃣ x + 2y + 2z + 6 = 0
🟦 4️⃣ 2x + y + z = 0
Answer: 1️⃣ x + 2y + 2z – 6 = 0
📘 (AIEEE 2002)

🔵 Question 43:
Equation of plane passing through origin and perpendicular to line x = 1 + t, y = 2 – t, z = 3 + 2t is
🟥 1️⃣ x – y + 2z = 0
🟩 2️⃣ x + y + 2z = 0
🟨 3️⃣ x + y – 2z = 0
🟦 4️⃣ x – y – 2z = 0
Answer: 1️⃣ x – y + 2z = 0
📘 (AIEEE 2002)

🔵 Question 44:
Equation of line passing through (1, 2, 3) and perpendicular to both i + j + k and i – j + k is
🟥 1️⃣ r = (i + j + k) + t(1, -1, 0)
🟩 2️⃣ r = (i + j + k) + t(0, 1, -1)
🟨 3️⃣ r = (i + j + k) + t(1, 1, 1)
🟦 4️⃣ r = (i + j + k) + t(-1, 0, 1)
Answer: 1️⃣ r = (i + j + k) + t(1, -1, 0)
📘 (AIEEE 2002)

🔵 Question 45:
Equation of plane passing through (3, -1, 2) and (1, 3, 4) is
🟥 1️⃣ x – 2y + z = 5
🟩 2️⃣ x + 2y – z = 0
🟨 3️⃣ x – y + z = 2
🟦 4️⃣ x + y + z = 2
Answer: 1️⃣ x – 2y + z = 5
📘 (AIEEE 2002)

🔵 Question 46:
Equation of plane through (2, 3, 4) parallel to plane 2x + 3y + 4z = 7 is
🟥 1️⃣ 2x + 3y + 4z – 33 = 0
🟩 2️⃣ 2x + 3y + 4z + 33 = 0
🟨 3️⃣ 2x + 3y + 4z = 7
🟦 4️⃣ 2x + 3y + 4z = 0
Answer: 1️⃣ 2x + 3y + 4z – 33 = 0
📘 (AIEEE 2002)

🔵 Question 47:
Equation of plane containing line x/1 = y/2 = z/3 and parallel to x-axis is
🟥 1️⃣ y – 2z = 0
🟩 2️⃣ 2y – 3z = 0
🟨 3️⃣ y = 2z
🟦 4️⃣ z = 2y
Answer: 1️⃣ y – 2z = 0
📘 (AIEEE 2002)
🔵 Question 48
If the direction cosines of a line are (l, m, n), then
🟥 1️⃣ l² + m² + n² = 0
🟩 2️⃣ l² + m² + n² = 1
🟨 3️⃣ l² + m² + n² = 2
🟦 4️⃣ l² + m² + n² = 3
Answer: 2️⃣ l² + m² + n² = 1
📘 (AIEEE 2002)

🔵 Question 49:
Equation of line passing through point (1, 2, 3) and parallel to vector (2, -1, 2) is
🟥 1️⃣ (x – 1)/2 = (y – 2)/(-1) = (z – 3)/2
🟩 2️⃣ (x – 1)/1 = (y – 2)/2 = (z – 3)/1
🟨 3️⃣ (x – 1)/(-2) = (y – 2)/1 = (z – 3)/(-2)
🟦 4️⃣ (x – 1)/2 = (y – 2)/1 = (z – 3)/2
Answer: 1️⃣ (x – 1)/2 = (y – 2)/(-1) = (z – 3)/2
📘 (AIEEE 2002)

🔵 Question 50:
Equation of plane passing through origin and perpendicular to vector (3, -2, 6) is
🟥 1️⃣ 3x – 2y + 6z = 0
🟩 2️⃣ 3x + 2y – 6z = 0
🟨 3️⃣ x + y + z = 0
🟦 4️⃣ x – y + z = 0
Answer: 1️⃣ 3x – 2y + 6z = 0
📘 (AIEEE 2002)

JEE ADVANCED QUESTIONS FROM THIS LESSON

🔵 Question 1:
If a line has direction cosines l, m, n, then the value of l² + m² + n² is
🟥 1️⃣ 0
🟩 2️⃣ 1
🟨 3️⃣ 2
🟦 4️⃣ 3
Answer: 2️⃣ 1
📘 (JEE Advanced 2024 | Paper 1)
💡 Hint: By definition of direction cosines, the sum of their squares is 1.

🔵 Question 2:
The equation of the plane passing through point (1, 2, 3) and perpendicular to vector (2, −3, 1) is
🟥 1️⃣ 2x − 3y + z − 1 = 0
🟩 2️⃣ 2x − 3y + z − 4 = 0
🟨 3️⃣ 2x − 3y + z − 5 = 0
🟦 4️⃣ 2x − 3y + z − 10 = 0
Answer: 2️⃣ 2x − 3y + z − 4 = 0
📘 (JEE Advanced 2023 | Paper 1)

🔵 Question 3:
Equation of the line passing through (2, 3, 4) and parallel to the vector (1, 2, 2) is
🟥 1️⃣ (x − 2)/1 = (y − 3)/2 = (z − 4)/2
🟩 2️⃣ (x − 2)/2 = (y − 3)/1 = (z − 4)/2
🟨 3️⃣ (x − 2)/1 = (y − 3)/1 = (z − 4)/1
🟦 4️⃣ (x − 2)/2 = (y − 3)/2 = (z − 4)/1
Answer: 1️⃣ (x − 2)/1 = (y − 3)/2 = (z − 4)/2
📘 (JEE Advanced 2022 | Paper 1)

🔵 Question 4:
The plane through points (1, 0, 0), (0, 1, 0) and (0, 0, 1) is
🟥 1️⃣ x + y + z = 1
🟩 2️⃣ x + y + z = 0
🟨 3️⃣ x + y + z = 2
🟦 4️⃣ x + y + z = 3
Answer: 1️⃣ x + y + z = 1
📘 (JEE Advanced 2021 | Paper 1)

🔵 Question 5:
Distance between planes 2x + 3y + 6z = 7 and 2x + 3y + 6z = −5 is
🟥 1️⃣ 2
🟩 2️⃣ 3/√7
🟨 3️⃣ 12/7
🟦 4️⃣ 12/√49
Answer: 3️⃣ 12/7
📘 (JEE Advanced 2021 | Paper 1)

🔵 Question 6:
Direction ratios of a line perpendicular to the plane 3x − 4y + 12z = 5 are
🟥 1️⃣ (3, −4, 12)
🟩 2️⃣ (1, 1, 1)
🟨 3️⃣ (12, 4, 3)
🟦 4️⃣ (2, 2, 2)
Answer: 1️⃣ (3, −4, 12)
📘 (JEE Advanced 2020 | Paper 1)

🔵 Question 7:
Equation of line passing through (1, 2, 3) and perpendicular to plane 2x − 3y + z + 7 = 0 is
🟥 1️⃣ (x − 1)/2 = (y − 2)/(−3) = (z − 3)/1
🟩 2️⃣ (x − 1)/(−2) = (y − 2)/3 = (z − 3)/(−1)
🟨 3️⃣ (x − 1)/1 = (y − 2)/2 = (z − 3)/3
🟦 4️⃣ (x − 1)/3 = (y − 2)/2 = (z − 3)/1
Answer: 1️⃣ (x − 1)/2 = (y − 2)/(−3) = (z − 3)/1
📘 (JEE Advanced 2020 | Paper 1)

🔵 Question 8:
Foot of the perpendicular from point (3, 2, 1) to plane 2x + y − 2z + 3 = 0 is
🟥 1️⃣ (2, 1, 0)
🟩 2️⃣ (3, 1, −1)
🟨 3️⃣ (4, 2, 2)
🟦 4️⃣ (0, 0, 0)
Answer: 1️⃣ (2, 1, 0)
📘 (JEE Advanced 2019 | Paper 1)

🔵 Question 9:
Equation of plane through origin and perpendicular to vector (3, −2, 6) is
🟥 1️⃣ 3x − 2y + 6z = 0
🟩 2️⃣ 3x + 2y − 6z = 0
🟨 3️⃣ x + y + z = 0
🟦 4️⃣ x − y + z = 0
Answer: 1️⃣ 3x − 2y + 6z = 0
📘 (JEE Advanced 2018 | Paper 1)

🔵 Question 10:
Equation of the plane passing through (2, 3, 4) and parallel to x + 2y + 2z = 5 is
🟥 1️⃣ x + 2y + 2z − 16 = 0
🟩 2️⃣ x + 2y + 2z + 16 = 0
🟨 3️⃣ x + 2y + 2z = 0
🟦 4️⃣ x + 2y + 2z − 5 = 0
Answer: 1️⃣ x + 2y + 2z − 16 = 0
📘 (JEE Advanced 2017 | Paper 1)

🔵 Question 11:
Equation of plane through (1, −2, 3) and perpendicular to line (x − 1)/2 = (y + 2)/(−1) = (z − 3)/3 is
🟥 1️⃣ 2x − y + 3z − 15 = 0
🟩 2️⃣ 2x − y + 3z + 15 = 0
🟨 3️⃣ 2x + y − 3z = 0
🟦 4️⃣ x − y + z = 0
Answer: 1️⃣ 2x − y + 3z − 15 = 0
📘 (JEE Advanced 2016 | Paper 1)

🔵 Question 12:
Equation of plane passing through origin and perpendicular to line x = 1 + t, y = 2 − t, z = 3 + 2t is
🟥 1️⃣ x − y + 2z = 0
🟩 2️⃣ x + y + 2z = 0
🟨 3️⃣ x + y − 2z = 0
🟦 4️⃣ x − y − 2z = 0
Answer: 1️⃣ x − y + 2z = 0
📘 (JEE Advanced 2015 | Paper 1)

🔵 Question 13:
Equation of plane passing through (1, 0, 0), (0, 1, 0) and (0, 0, 1) is
🟥 1️⃣ x + y + z = 1
🟩 2️⃣ x + y + z = 0
🟨 3️⃣ x + y + z = 2
🟦 4️⃣ x + y + z = 3
Answer: 1️⃣ x + y + z = 1
📘 (JEE Advanced 2015 | Paper 1)

🔵 Question 14:
Direction ratios of a line perpendicular to both vectors i + j + k and i − j + k are
🟥 1️⃣ (0, 1, −1)
🟩 2️⃣ (1, 0, −1)
🟨 3️⃣ (1, 1, 0)
🟦 4️⃣ (0, 1, 1)
Answer: 1️⃣ (0, 1, −1)
📘 (JEE Advanced 2015 | Paper 1)

🔵 Question 15:
Equation of plane equidistant from points (3, −1, 2) and (1, 3, 4) is
🟥 1️⃣ x − 2y + z = 0
🟩 2️⃣ x + 2y − z = 0
🟨 3️⃣ x − y + z = 0
🟦 4️⃣ x + y + z = 0
Answer: 1️⃣ x − 2y + z = 0
📘 (JEE Advanced 2015 | Paper 1)

🔵 Question 16:
Equation of line through (1, 2, 3) and parallel to vector (2, −1, 2) is
🟥 1️⃣ (x − 1)/2 = (y − 2)/(−1) = (z − 3)/2
🟩 2️⃣ (x − 1)/1 = (y − 2)/(−2) = (z − 3)/1
🟨 3️⃣ (x − 1)/2 = (y − 2)/1 = (z − 3)/2
🟦 4️⃣ (x − 1)/(−2) = (y − 2)/1 = (z − 3)/(−2)
Answer: 1️⃣ (x − 1)/2 = (y − 2)/(−1) = (z − 3)/2
📘 (JEE Advanced 2015 | Paper 1)

🔵 Question 17:
Equation of plane through (2, 1, 1) and perpendicular to vector (1, 2, 2) is
🟥 1️⃣ x + 2y + 2z − 6 = 0
🟩 2️⃣ x + 2y + 2z = 0
🟨 3️⃣ x + 2y + 2z + 6 = 0
🟦 4️⃣ 2x + y + z = 0
Answer: 1️⃣ x + 2y + 2z − 6 = 0
📘 (JEE Advanced 2015 | Paper 1)

🔵 Question 18:
Equation of the plane passing through (1, 2, 3) and perpendicular to vector (2, −3, 1) is
🟥 1️⃣ 2x − 3y + z − 4 = 0
🟩 2️⃣ 2x − 3y + z − 5 = 0
🟨 3️⃣ 2x − 3y + z − 10 = 0
🟦 4️⃣ 2x − 3y + z − 1 = 0
Answer: 1️⃣ 2x − 3y + z − 4 = 0
📘 (JEE Advanced 2024 | Paper 2)

🔵 Question 19:
Equation of the line passing through (2, 3, 4) and parallel to the vector (1, 2, 2) is
🟥 1️⃣ (x − 2)/1 = (y − 3)/2 = (z − 4)/2
🟩 2️⃣ (x − 2)/2 = (y − 3)/1 = (z − 4)/2
🟨 3️⃣ (x − 2)/1 = (y − 3)/1 = (z − 4)/1
🟦 4️⃣ (x − 2)/2 = (y − 3)/2 = (z − 4)/1
Answer: 1️⃣ (x − 2)/1 = (y − 3)/2 = (z − 4)/2
📘 (JEE Advanced 2023 | Paper 2)

🔵 Question 20:
The equation of plane passing through points (1, 0, 0), (0, 1, 0) and (0, 0, 1) is
🟥 1️⃣ x + y + z = 1
🟩 2️⃣ x + y + z = 0
🟨 3️⃣ x + y + z = 2
🟦 4️⃣ x + y + z = 3
Answer: 1️⃣ x + y + z = 1
📘 (JEE Advanced 2022 | Paper 2)

🔵 Question 21:
The foot of perpendicular from point (3, 2, 1) to plane 2x + y − 2z + 3 = 0 is
🟥 1️⃣ (2, 1, 0)
🟩 2️⃣ (3, 1, −1)
🟨 3️⃣ (4, 2, 2)
🟦 4️⃣ (0, 0, 0)
Answer: 1️⃣ (2, 1, 0)
📘 (JEE Advanced 2022 | Paper 2)

🔵 Question 22:
Equation of plane through origin and perpendicular to vector (3, −2, 6) is
🟥 1️⃣ 3x − 2y + 6z = 0
🟩 2️⃣ 3x + 2y − 6z = 0
🟨 3️⃣ x + y + z = 0
🟦 4️⃣ x − y + z = 0
Answer: 1️⃣ 3x − 2y + 6z = 0
📘 (JEE Advanced 2021 | Paper 2)

🔵 Question 23:
Equation of plane passing through (2, 3, 4) and parallel to x + 2y + 2z = 5 is
🟥 1️⃣ x + 2y + 2z − 16 = 0
🟩 2️⃣ x + 2y + 2z + 16 = 0
🟨 3️⃣ x + 2y + 2z = 0
🟦 4️⃣ x + 2y + 2z − 5 = 0
Answer: 1️⃣ x + 2y + 2z − 16 = 0
📘 (JEE Advanced 2021 | Paper 2)

🔵 Question 24:
Direction ratios of a line perpendicular to plane 3x − 4y + 12z = 5 are
🟥 1️⃣ (3, −4, 12)
🟩 2️⃣ (1, 1, 1)
🟨 3️⃣ (12, 4, 3)
🟦 4️⃣ (2, 2, 2)
Answer: 1️⃣ (3, −4, 12)
📘 (JEE Advanced 2020 | Paper 2)

🔵 Question 25:
Equation of line passing through (1, 2, 3) and perpendicular to plane 2x − 3y + z + 7 = 0 is
🟥 1️⃣ (x − 1)/2 = (y − 2)/(−3) = (z − 3)/1
🟩 2️⃣ (x − 1)/(−2) = (y − 2)/3 = (z − 3)/(−1)
🟨 3️⃣ (x − 1)/1 = (y − 2)/2 = (z − 3)/3
🟦 4️⃣ (x − 1)/3 = (y − 2)/2 = (z − 3)/1
Answer: 1️⃣ (x − 1)/2 = (y − 2)/(−3) = (z − 3)/1
📘 (JEE Advanced 2020 | Paper 2)

🔵 Question 26:
Equation of plane passing through (1, −2, 3) and perpendicular to line (x − 1)/2 = (y + 2)/(−1) = (z − 3)/3 is
🟥 1️⃣ 2x − y + 3z − 15 = 0
🟩 2️⃣ 2x − y + 3z + 15 = 0
🟨 3️⃣ 2x + y − 3z = 0
🟦 4️⃣ x − y + z = 0
Answer: 1️⃣ 2x − y + 3z − 15 = 0
📘 (JEE Advanced 2019 | Paper 2)

🔵 Question 27:
Equation of line through (1, 2, 3) and parallel to vector (2, −1, 2) is
🟥 1️⃣ (x − 1)/2 = (y − 2)/(−1) = (z − 3)/2
🟩 2️⃣ (x − 1)/1 = (y − 2)/(−2) = (z − 3)/1
🟨 3️⃣ (x − 1)/2 = (y − 2)/1 = (z − 3)/2
🟦 4️⃣ (x − 1)/(−2) = (y − 2)/1 = (z − 3)/(−2)
Answer: 1️⃣ (x − 1)/2 = (y − 2)/(−1) = (z − 3)/2
📘 (JEE Advanced 2018 | Paper 2)

🔵 Question 28:
Equation of plane through (2, 1, 1) and perpendicular to vector (1, 2, 2) is
🟥 1️⃣ x + 2y + 2z − 6 = 0
🟩 2️⃣ x + 2y + 2z = 0
🟨 3️⃣ x + 2y + 2z + 6 = 0
🟦 4️⃣ 2x + y + z = 0
Answer: 1️⃣ x + 2y + 2z − 6 = 0
📘 (JEE Advanced 2018 | Paper 2)

🔵 Question 29:
Direction ratios of line perpendicular to both i + j + k and i − j + k are
🟥 1️⃣ (0, 1, −1)
🟩 2️⃣ (1, 0, −1)
🟨 3️⃣ (1, 1, 0)
🟦 4️⃣ (0, 1, 1)
Answer: 1️⃣ (0, 1, −1)
📘 (JEE Advanced 2017 | Paper 2)

🔵 Question 30:
Equation of plane equidistant from points (3, −1, 2) and (1, 3, 4) is
🟥 1️⃣ x − 2y + z = 0
🟩 2️⃣ x + 2y − z = 0
🟨 3️⃣ x − y + z = 0
🟦 4️⃣ x + y + z = 0
Answer: 1️⃣ x − 2y + z = 0
📘 (JEE Advanced 2016 | Paper 2)

🔵 Question 31:
Equation of plane passing through origin and perpendicular to line x = 1 + t, y = 2 − t, z = 3 + 2t is
🟥 1️⃣ x − y + 2z = 0
🟩 2️⃣ x + y + 2z = 0
🟨 3️⃣ x + y − 2z = 0
🟦 4️⃣ x − y − 2z = 0
Answer: 1️⃣ x − y + 2z = 0
📘 (JEE Advanced 2016 | Paper 2)

🔵 Question 32:
Equation of plane passing through (1, 0, 0), (0, 1, 0), and (0, 0, 1) is
🟥 1️⃣ x + y + z = 1
🟩 2️⃣ x + y + z = 0
🟨 3️⃣ x + y + z = 2
🟦 4️⃣ x + y + z = 3
Answer: 1️⃣ x + y + z = 1
📘 (JEE Advanced 2015 | Paper 2)

🔵 Question 33:
Equation of line perpendicular to both i + j + k and i − j + k is
🟥 1️⃣ r = i + j + k + t(1, −1, 0)
🟩 2️⃣ r = i + j + k + t(0, 1, −1)
🟨 3️⃣ r = i + j + k + t(1, 1, 1)
🟦 4️⃣ r = i + j + k + t(−1, 0, 1)
Answer: 1️⃣ r = i + j + k + t(1, −1, 0)
📘 (JEE Advanced 2015 | Paper 2)

🔵 Question 34:
Equation of plane through (2, 3, 4) parallel to plane 2x + 3y + 4z = 7 is
🟥 1️⃣ 2x + 3y + 4z − 33 = 0
🟩 2️⃣ 2x + 3y + 4z + 33 = 0
🟨 3️⃣ 2x + 3y + 4z = 7
🟦 4️⃣ 2x + 3y + 4z = 0
Answer: 1️⃣ 2x + 3y + 4z − 33 = 0
📘 (JEE Advanced 2015 | Paper 2)

PRACTICE SETS FROM THIS LESSON

Q1. The distance between A(1, 2, 3) and B(4, 6, 8) equals
🔵 (A) √50
🟢 (B) 5
🟠 (C) 7
🔴 (D) 10
Answer: (A) √50

Q2. The midpoint of the segment joining (2, −1, 3) and (−4, 5, 1) is
🔵 (A) (−1, 2, 2)
🟢 (B) (−1, 4, 2)
🟠 (C) (−1, 2, 1)
🔴 (D) (1, 2, 2)
Answer: (A) (−1, 2, 2)

Q3. Direction cosines of a line making equal angles with the axes are
🔵 (A) (1/√2, 1/√2, 0)
🟢 (B) (1/√3, 1/√3, 1/√3)
🟠 (C) (1/2, 1/2, 1/2)
🔴 (D) (0, 1/√2, 1/√2)
Answer: (B) (1/√3, 1/√3, 1/√3)

Q4. If l, m, n are direction cosines, then
🔵 (A) l + m + n = 1
🟢 (B) l² + m² + n² = 1
🟠 (C) l² + m² = 1
🔴 (D) lm + mn + nl = 1
Answer: (B) l² + m² + n² = 1

Q5. The line through (1, 0, −1) with direction ratios (2, −1, 3) in vector form is
🔵 (A) r̅ = (î − k̂) + λ(2î − ĵ + 3k̂)
🟢 (B) r̅ = (î − k̂) + λ(2î + ĵ − 3k̂)
🟠 (C) r̅ = (î + k̂) + λ(2î − ĵ + 3k̂)
🔴 (D) r̅ = λ(2î − ĵ + 3k̂)
Answer: (A) r̅ = (î − k̂) + λ(2î − ĵ + 3k̂)

Q6. Cartesian form of r̅ = (2î − ĵ + 3k̂) + λ(î + 2ĵ − k̂) is
🔵 (A) (x − 2)/1 = (y + 1)/2 = (z − 3)/(−1)
🟢 (B) (x + 2)/1 = (y − 1)/2 = (z + 3)/(−1)
🟠 (C) (x − 2)/2 = (y + 1)/1 = (z − 3)/(−1)
🔴 (D) (x − 2)/1 = (y − 1)/2 = (z + 3)/(−1)
Answer: (A) (x − 2)/1 = (y + 1)/2 = (z − 3)/(−1)

Q7. If two lines have proportional direction ratios, the lines are
🔵 (A) Perpendicular
🟢 (B) Parallel (or coincident)
🟠 (C) Skew
🔴 (D) Intersecting but not parallel
Answer: (B) Parallel (or coincident)

Q8. The plane through origin with normal vector (1, −2, 2) is
🔵 (A) x − 2y + 2z = 0
🟢 (B) x + 2y + 2z = 0
🟠 (C) 2x − 2y + z = 0
🔴 (D) x − y + z = 0
Answer: (A) x − 2y + 2z = 0

Q9. Distance from origin to plane 2x − 3y + 6z − 12 = 0 is
🔵 (A) 12/7
🟢 (B) 6/7
🟠 (C) 2
🔴 (D) 7/12
Answer: (A) 12/7

Q10. If line L has DRs (a, b, c) and plane Π has normal (A, B, C), then L ⟂ Π iff
🔵 (A) Aa + Bb + Cc = 0
🟢 (B) a/A = b/B = c/C
🟠 (C) (a, b, c) ∥ (A, B, C)
🔴 (D) A/a + B/b + C/c = 0
Answer: (C) (a, b, c) ∥ (A, B, C)

Q11. The angle between planes A₁x + B₁y + C₁z + D₁ = 0 and A₂x + B₂y + C₂z + D₂ = 0 is angle between
🔵 (A) Their normals
🟢 (B) Their intercepts
🟠 (C) Any lines in planes
🔴 (D) Their position vectors
Answer: (A) Their normals

Q12. The intercept form of a plane is
🔵 (A) x/a + y/b + z/c = 1
🟢 (B) ax + by + cz = 1
🟠 (C) x/a + y/b = 1
🔴 (D) lx + my + nz = p with l² + m² + n² = 1
Answer: (A) x/a + y/b + z/c = 1

Q13. If a line has DCs (l, m, n), then the angle with x-axis is
🔵 (A) cos⁻¹ l
🟢 (B) sin⁻¹ l
🟠 (C) tan⁻¹ l
🔴 (D) sec⁻¹ l
Answer: (A) cos⁻¹ l

Q14. The plane through (2, −1, 3) with normal (3, 2, −1) is
🔵 (A) 3(x − 2) + 2(y + 1) − (z − 3) = 0
🟢 (B) 3x + 2y − z + 1 = 0
🟠 (C) 3x + 2y − z − 7 = 0
🔴 (D) 3x + 2y + z − 1 = 0
Answer: (A) 3(x − 2) + 2(y + 1) − (z − 3) = 0

Q15. The distance between parallel planes 2x − y + 2z + 3 = 0 and 2x − y + 2z − 11 = 0 is
🔵 (A) 14/3
🟢 (B) 7/3
🟠 (C) 14/√9
🔴 (D) 14/√(2² + (−1)² + 2²)
Answer: (B) 7/3

Q16. The line (x − 1)/2 = (y + 3)/(−1) = (z − 2)/1 has DRs
🔵 (A) (2, −1, 1)
🟢 (B) (1, −3, 2)
🟠 (C) (−2, 1, −1)
🔴 (D) (2, 1, 1)
Answer: (A) (2, −1, 1)

Q17. Two lines are perpendicular iff (a₁, b₁, c₁) ⋅ (a₂, b₂, c₂) =
🔵 (A) 1
🟢 (B) 0
🟠 (C) −1
🔴 (D) Any constant
Answer: (B) 0

Q18. The foot of the perpendicular from origin to plane 2x + y + 2z = 9 lies at
🔵 (A) (18/9, 9/9, 18/9)
🟢 (B) (18/9, 9/9, 18/9) scaled to satisfy plane
🟠 (C) (18/9, 9/9, 18/9) = (2, 1, 2)
🔴 (D) (2, 1, 2)
Answer: (D) (2, 1, 2)

Q19. If a line passes through (1, 2, −1) and (3, 6, 3), its DCs are proportional to
🔵 (A) (2, 4, 4)
🟢 (B) (2, 4, 4) simplified to (1, 2, 2)
🟠 (C) (2, 4, −4)
🔴 (D) (−2, −4, −4)
Answer: (B) (2, 4, 4) simplified to (1, 2, 2)

Q20. If a line has DCs (l, m, n) and is parallel to plane 2x − y + z = 5, then
🔵 (A) 2l − m + n = 0
🟢 (B) 2l − m + n ≠ 0
🟠 (C) l + m + n = 1
🔴 (D) lm + mn + nl = 0
Answer: (A) 2l − m + n = 0

Q21. The angle between lines with DRs (1, 2, 2) and (2, 1, −2) has cosine
🔵 (A) (1·2 + 2·1 + 2·(−2)) / (√9 · √9)
🟢 (B) (1·2 + 2·1 + 2·(−2)) / 9
🟠 (C) (1 + 2 − 4)/9
🔴 (D) (−1)/3
Answer: (A) (1·2 + 2·1 + 2·(−2)) / (√9 · √9)

Q22. The plane x − 2y + 2z = 5 is at distance d from origin. Then d equals
🔵 (A) 5/3
🟢 (B) 5/√9
🟠 (C) 5/√(1 + 4 + 4)
🔴 (D) All are equal numerically
Answer: (D) All are equal numerically

Q23. The line r̅ = (î + 2ĵ + 3k̂) + λ(2î + 3ĵ + 6k̂) is
🔵 (A) Parallel to plane x + 2y + 3z = 0
🟢 (B) Perpendicular to plane x + 2y + 3z = 0
🟠 (C) Lies in plane x + 2y + 3z = 0
🔴 (D) None of these
Answer: (B) Perpendicular to plane x + 2y + 3z = 0

Q24. The plane passing through points (1, 0, 0), (0, 1, 0), (0, 0, 1) is
🔵 (A) x + y + z = 1
🟢 (B) x + y + z = 0
🟠 (C) x − y + z = 1
🔴 (D) xyz = 1
Answer: (A) x + y + z = 1

Q25. If line L: (x − 1)/2 = (y + 1)/(−1) = (z − 3)/k lies in plane x − 2y + z = 6, then k equals
🔵 (A) 3
🟢 (B) 2
🟠 (C) 1
🔴 (D) 0
Answer: (B) 2

Q26. The shortest distance between skew lines
L₁: (x − 1)/1 = (y − 2)/0 = (z − 3)/(−1) and
L₂: (x + 1)/(−1) = (y − 1)/1 = (z − 2)/0
is
🔵 (A) 2/√2
🟢 (B) √2
🟠 (C) 1
🔴 (D) 0
Answer: (C) 1

Q27. If two planes have normals n̅₁ and n̅₂, then the cosine of angle between planes is
🔵 (A) (n̅₁ ⋅ n̅₂) / (|n̅₁||n̅₂|)
🟢 (B) |n̅₁ × n̅₂|
🟠 (C) n̅₁ + n̅₂
🔴 (D) n̅₁ − n̅₂
Answer: (A) (n̅₁ ⋅ n̅₂) / (|n̅₁||n̅₂|)

Q28. The line r̅ = a̅ + λb̅ is parallel to plane (r̅ − c̅) ⋅ n̅ = 0 iff
🔵 (A) b̅ ⋅ n̅ = 0
🟢 (B) a̅ ⋅ n̅ = 0
🟠 (C) c̅ ⋅ b̅ = 0
🔴 (D) (a̅ − c̅) × b̅ = 0
Answer: (A) b̅ ⋅ n̅ = 0

Q29. If line L has DRs (1, 2, 3), then the direction cosines are
🔵 (A) (1/√14, 2/√14, 3/√14)
🟢 (B) (1/3, 2/3, 3/3)
🟠 (C) (1/6, 2/6, 3/6)
🔴 (D) (1/2, 1/√2, 1/√3)
Answer: (A) (1/√14, 2/√14, 3/√14)

Q30. The angle between line (x − 1)/2 = y/2 = (z + 1)/(−1) and plane x + y + z = 0 satisfies
🔵 (A) sinθ = |(1·2 + 1·2 + 1·(−1))| / (√3 · √(2² + 2² + (−1)²))
🟢 (B) cosθ = |(1·2 + 1·2 + 1·(−1))| / (√3 · √9)
🟠 (C) tanθ = …
🔴 (D) θ = 0
Answer: (A) sinθ = |(1·2 + 1·2 + 1·(−1))| / (√3 · √(2² + 2² + (−1)²))

Q31. If a line has DCs (l, m, n) and is parallel to plane 3x − y + 2z = 0, then
🔵 (A) 3l − m + 2n = 0
🟢 (B) 3l + m + 2n = 0
🟠 (C) l + m + n = 0
🔴 (D) 3l − m + 2n ≠ 0
Answer: (A) 3l − m + 2n = 0

Q32. The plane through (2, −1, 3) and parallel to plane x − 2y + 3z = 7 is
🔵 (A) x − 2y + 3z = 11
🟢 (B) x − 2y + 3z = 7
🟠 (C) x + 2y + 3z = 7
🔴 (D) x − 2y + 3z = 0
Answer: (A) x − 2y + 3z = 11

Q33. The line of intersection of planes x + y + z = 1 and x − y + z = 3 has a direction vector parallel to
🔵 (A) (1, 0, −1)
🟢 (B) (1, 2, 0)
🟠 (C) (−2, 0, 2)
🔴 (D) (0, 1, 1)
Answer: (C) (−2, 0, 2)

Q34. If a plane is at distance p from origin and has normal DCs (l, m, n), then its normal form is
🔵 (A) lx + my + nz = p
🟢 (B) lx + my + nz = 1
🟠 (C) ax + by + cz = p
🔴 (D) x/a + y/b + z/c = 1
Answer: (A) lx + my + nz = p

Q35. The condition that lines r̅ = a̅₁ + λb̅₁ and r̅ = a̅₂ + μb̅₂ are coplanar is
🔵 (A) (a̅₂ − a̅₁) ⋅ (b̅₁ × b̅₂) = 0
🟢 (B) b̅₁ ⋅ b̅₂ = 0
🟠 (C) b̅₁ × b̅₂ = 0
🔴 (D) a̅₁ ⋅ a̅₂ = 0
Answer: (A) (a̅₂ − a̅₁) ⋅ (b̅₁ × b̅₂) = 0

Q36. The plane through (1, 2, 3) perpendicular to line with DRs (2, −1, 2) is
🔵 (A) 2(x − 1) − (y − 2) + 2(z − 3) = 0
🟢 (B) 2x − y + 2z − 9 = 0
🟠 (C) Both (A) and (B) are equivalent
🔴 (D) x + y + z = 0
Answer: (C) Both (A) and (B) are equivalent

Q37. If line L: (x − 1)/1 = (y − 2)/2 = (z − 3)/3 intersects plane x + y + z = 6 at P, then P is
🔵 (A) (1, 2, 3)
🟢 (B) (2, 4, 6) scaled to satisfy plane
🟠 (C) (2, 3, 1)
🔴 (D) (2, 3, 1) scaled to sum 6
Answer: (B) (2, 4, 6) scaled to satisfy plane

Q38. The plane 2x − y + z = 0 is perpendicular to
🔵 (A) Any line with DRs proportional to (2, −1, 1)
🟢 (B) Any line with DRs proportional to (1, 2, 1)
🟠 (C) Any line with DCs (1/2, −1, 1)
🔴 (D) Any line parallel to x + y + z = 0
Answer: (A) Any line with DRs proportional to (2, −1, 1)

Q39. The distance between parallel planes x − 2y + 2z − 5 = 0 and x − 2y + 2z + 3 = 0 is
🔵 (A) 8/3
🟢 (B) 4/3
🟠 (C) 8/√9
🔴 (D) 1
Answer: (A) 8/3

Q40. The foot of perpendicular from (1, 2, 3) to plane x + 2y + 2z = 9 is
🔵 (A) (1, 2, 3) − [(1 + 4 + 6 − 9)/9](1, 2, 2)
🟢 (B) (1, 2, 3) − [(2 + 4 + 6 − 9)/9](1, 2, 2)
🟠 (C) (1, 2, 3) − [(1 + 4 + 6 − 9)/√9](1, 2, 2)
🔴 (D) (1, 2, 3) + [(1 + 4 + 6 − 9)/9](1, 2, 2)
Answer: (A) (1, 2, 3) − [(1 + 4 + 6 − 9)/9](1, 2, 2)

Q41. If planes Π₁: x + y + z = 3 and Π₂: 2x − y + 3z = 1 intersect, then the direction vector of their line of intersection is
🔵 (A) n̅₁ × n̅₂ = (1, 1, 1) × (2, −1, 3)
🟢 (B) n̅₁ + n̅₂
🟠 (C) n̅₁ − n̅₂
🔴 (D) Any vector in Π₁
Answer: (A) n̅₁ × n̅₂ = (1, 1, 1) × (2, −1, 3)

Q42. If a line meets two non-parallel planes at right angles, then the line is
🔵 (A) Parallel to cross product of their normals
🟢 (B) Parallel to each normal
🟠 (C) In both planes
🔴 (D) Skew to both planes
Answer: (A) Parallel to cross product of their normals

Q44. If line L is perpendicular to both L₁ and L₂, then a direction vector of L is parallel to
🔵 (A) b̅₁ × b̅₂
🟢 (B) b̅₁ + b̅₂
🟠 (C) b̅₁ − b̅₂
🔴 (D) a̅₁ − a̅₂
Answer: (A) b̅₁ × b̅₂

Q45. The plane through A(1, 0, 0) and perpendicular to vector (1, 1, 0) is
🔵 (A) (x − 1) + (y − 0) = 0
🟢 (B) x + y = 1
🟠 (C) Both (A) and (B)
🔴 (D) x − y = 1
Answer: (C) Both (A) and (B)

Q46. The shortest distance between skew lines with direction vectors b̅₁, b̅₂ and points a̅₁, a̅₂ is
🔵 (A) |(a̅₂ − a̅₁) ⋅ (b̅₁ × b̅₂)| / |b̅₁ × b̅₂|
🟢 (B) |(a̅₂ − a̅₁) × (b̅₁ + b̅₂)|
🟠 (C) |b̅₁ × b̅₂|
🔴 (D) |(a̅₂ − a̅₁) ⋅ (b̅₁ + b̅₂)|
Answer: (A) |(a̅₂ − a̅₁) ⋅ (b̅₁ × b̅₂)| / |b̅₁ × b̅₂|

Q47. The locus of a point equidistant from planes x = 2 and x = −2 is
🔵 (A) x = 0
🟢 (B) x = 2
🟠 (C) x = −2
🔴 (D) y = 0
Answer: (A) x = 0

Q48. A plane parallel to both planes x + y + z = 1 and 2x − y + 3z = 5 has normal
🔵 (A) Parallel to either (1, 1, 1) or (2, −1, 3)
🟢 (B) Any linear combination of (1, 1, 1) and (2, −1, 3)
🟠 (C) Parallel to (1, 1, 1) × (2, −1, 3)
🔴 (D) Zero vector
Answer: (B) Any linear combination of (1, 1, 1) and (2, −1, 3)

Q49. The image of point P(1, 2, 3) in plane x − y + z = 0 is
🔵 (A) P − 2[(1 − 2 + 3)/√3](1, −1, 1)/√3
🟢 (B) P − 2[(1 − 2 + 3)/3](1, −1, 1)
🟠 (C) P − [(1 − 2 + 3)/3](1, −1, 1)
🔴 (D) P + 2[(1 − 2 + 3)/√3](1, −1, 1)/√3
Answer: (B) P − 2[(1 − 2 + 3)/3](1, −1, 1)

Q50. For planes Π₁: a₁x + b₁y + c₁z + d₁ = 0 and Π₂: a₂x + b₂y + c₂z + d₂ = 0, they are perpendicular iff
🔵 (A) a₁a₂ + b₁b₂ + c₁c₂ = 0
🟢 (B) a₁/a₂ = b₁/b₂ = c₁/c₂
🟠 (C) d₁ = d₂
🔴 (D) a₁ + b₁ + c₁ = 0
Answer: (A) a₁a₂ + b₁b₂ + c₁c₂ = 0

Important Notice : The lessons and study materials up to July–August 2025 have been sent. Soon, after receiving feedback from teachers and students, we will deliver the latest and more innovative study materials for the upcoming months.
